Computer control T-shirt bag making machine(Two Lines)

Computer control T-shirt bag making machine(Two Lines)

Model No.︰CY-HC-600(700)

Brand Name︰CHANGYIN

Country of Origin︰China

Unit Price︰-

Minimum Order︰1 pc

Inquire Now

Product Description

CY-HC-600(700) Computer control T-shirt bag making machine(Two Lines)

Product  Application :
1.The machine suitable material is for HDPE,LDPE T-shirt bag automatically.,it Can make color or non-colored bag sealing, cutting and punching automatically.
Product instruction :
The machine controlled by computer, photo cell, inverter controll speed.It have such functions as stop machine immediately without material, auto-count. Punching with cylinder, auto conveyor belt.

CY-HC-600 computer control T-shirt bag making machine, if close the cylinder punching set, it can also make flat bag. It can make 4 lines if bag width is less than 250mm, with double cutting knife,If bag width is above 250mm,can make 2 lines.With single cutting knife.

Performance,characteristic and main technical data :

Mode
CY-HC-600
CY-HC-700
Max. Width of Sealing and cutting Roll Material 100-550mm 100-650mm
Max. Diameter of Sealing and cutting Roll Material 100-1200mm 100-900mm
Thickness of Material 0.01-0.10mm 0.01-0.10mm
Speed 30-120pcs/min 30-120pcs/min
Deviation rectifying Error ±1mm ±1mm
Total Power 1.1kw 1.1kw
Outline (L x W x H) 4800×1180×1600mm 4800×1200×1600mm
Weight 1100kg 1100kg

Product Image
